Description
Analog Inputs: 16 x XLR local microphone/line inputs, plus 6 x 1/4″ TRS Aux inputs (and 1 x XLR Talkback input).
Analog Outputs: 8 x XLR local outputs, plus 6 x 1/4″ TRS Aux outputs and stereo TRS monitor outputs.
Digital Networking: 2 x AES50 ports (allowing up to 96 inputs and 96 outputs via Cat5 digital snakes) and 1 x ULTRANET port for personal monitoring systems.
Display: 5-inch day-viewable high-resolution colour TFT display screen.Buses & Groups: 25 time-aligned, phase-coherent mix buses, 8 DCA groups, and 6 mute groups.
Dimensions & Weight: 478mm x 617mm x 208mm (18.8″ x 24.3″ x 8.2″) | Weight: 14.3 kg (31.5 lbs)
